How I work through a bad result

Three steps, every time

Every answer on these pages follows the same three steps. They are the steps I use on my own data.

  1. 1Look at the raw data first.

    The pattern before the map. The mass spectrum before the composition profile. The load curve before the hardness number. Most results that look wrong were fine until the software processed them.

  2. 2Blame the instrument before the sample.

    Drift, tilt, detector gain, the wrong camera length, a bad reconstruction parameter. Check every one of these before deciding the material did something strange.

  3. 3Get a second technique to agree.

    A feature that only one method can see is a hypothesis. When atom probe and 4D-STEM show the same thing in the same place, it is a result.

Can you trust this result?

Check before you conclude

Before a number goes in a paper: these guides walk through what the instrument actually measured, which artefacts look like results, and what evidence would settle it.

GuideSAED Indexing, g-Vectors & Real vs. Fake SpotsInteractive guide to indexing SAED patterns by hand: measure g-vectors from spot ratio and angle, see whether those two numbers name one zone axis or several at your measurement precision, and score a twin, double diffraction and a second phase against the same extra spots.GuideWhen Forbidden Reflections AppearInteractive guide to forbidden reflections and superlattices in TEM: why spots are systematically absent, the mechanisms that make them appear (double diffraction, relrods, stacking faults), and a field guide to superlattices in metals and alloys: chemical ordering, the omega phase, long-period structures and their look-alikes.ToolQuantitative HAADFPut an experimental HAADF-STEM image on an absolute scale in the browser: normalise to the detector dark level and probe current, find and refine the atomic columns, integrate each column over a disc or its Voronoi cell, read the statistics, and compare with the fraction-versus-thickness curves exported by the SAED simulator to estimate thickness and the Z-contrast exponent.ToolBend ContoursBend contours simulated in the browser: pick one of 604 crystals or a CIF, a zone axis and how the foil is bent, and see the many-beam Bloch-wave rocking surface painted on the bent foil as bright-field and dark-field images with the contour pairs, higher orders, fringes and bend centre; move the holder tilt and watch the contours slide, read the radius of curvature from the spacing, and get the eleven most asked questions about bend contours answered.GuideHRTEM & FFTsInteractive guide to HRTEM and FFTs: a defocus/CTF lattice-image simulator with a true atom-column overlay, the Scherzer-defocus CTF explorer, measuring d-spacings from an FFT with a draggable ROI, how Fourier filtering can make a lattice appear from noise, and FFT versus SAED.ToolGPA Strain MappingFree in-browser geometric phase analysis (GPA) lab: put a known strain into a lattice image of a metal or an oxide, add STEM scan drift, flyback and jitter, and watch every GPA step update live, then see how precisely one atomic column can be placed.
